Flexible Drag Chain Cable’s Specification
1. Flexible Drag Chain Cable, do not use the cable before you get it. In order to ensure that the cable can be easily installed under the optimal mechanical environment, the cable should be stored at room temperature for at least 24 hours before use.
2. The drag chain cable with the recommended bending radius above (R) shall be used. The cable life will vary greatly due to the mechanical impact borne by the cable and the installation and fixing methods on the cable.
3. When wiring, please ensure that the flexible drag chain cable is straight. If the wiring is directly connected in a twisted state, it will lead to premature disconnection. Please confirm whether the cable is twisted before wiring.
4. Do not fix the movable part of the drag chain cable. Otherwise, the fixed part will be subject to concentrated stress and lead to premature disconnection. Please try to reduce the fixed parts.
5. If the length of the drag chain cable is too long, it will lead to relaxation; if it is too short, it will lead to premature disconnection due to the tension of the fixed part. When using, please adjust the cable to the optimal length.
6. Please avoid mutual contact between bent cables. Otherwise, the cable will be disconnected prematurely due to the limited action of the cable. Please confirm whether the spacing between cables is sufficient and take measures such as using partitions.
In order to ensure the longest service life of the cable, the complete radius of the cable shall not be less than the recommended optimal radius
Extract the cable correctly
When pulling out the cable, in order to avoid twisting inside the cable, it should be taken out along the tangent direction of the cable spool or reel rolling, and then placed straight, so that the cable can be relaxed without stress. Pay attention not to pull the cable directly from the top of the cable coil, nor place the reel vertically, and then pull the cable from the top of the reel. These incorrect practices will cause unnecessary stress on the cable and easily lead to cable damage.
What are flexible drag chain cables used for ?
Flexible drag chain cables are used for a variety of applications where high flexibility, durability, and protection are required in cable routing. They are commonly used in automated machinery and equipment, such as CNC machines, robotics, machine tools, and assembly lines.
The drag chain cables are specifically designed to withstand repeated bending, twisting, and dragging movements without damage or performance degradation. They are often installed inside cable carrier systems or drag chains, which provide a protective enclosure and ensure proper cable management.
These cables typically have a high number of fine copper strands to ensure flexibility and resistance to fatigue. They are also insulated and shielded to provide reliable electrical transmission and protection against electromagnetic interference (EMI).
Flexible drag chain cables can carry various types of signals and power, including data signals, control signals, power supply, and communication signals. They play a crucial role in ensuring the smooth operation and reliable performance of automated machinery and systems by providing secure and protected cable routing.https://youtube.com/shorts/-BmVTo9RDcQ?si=n2yMDKcw_lEgf7i3
