Application: Hoist cable, also called electric hoist arm control cable, widely used in dry or wet indoor, can be forced to guide the installation of non-continuous movement, such as electric hoist, driving and inspection equipment, self-supporting well or inclined shelves, cranes, ports and other occasions. The outer sheath can be customized according to different weather conditions and use occasions, so this product can also be used in the open air.
Product Structure:
– 2 core 1.0mm2 (17AWG)
– 4 twisted pairs 24AWG
Conductor: Multiple strands of flexible oxygen free copper wire in accordance with DIN VDE 0295 grade 5
Insulation: High quality mixed PVC
Insulation color: Different color cores or code cores with yellow-green core.
Filling: High quality jute tensile rope
Strength member: Single or double non-torque self-bearing steel wire.
Outer Sheath: PVC
Color: Black
Rated voltage: 300/500V, 450/750V
Test voltage: 3000V
Min.bend radius: 20D
Temperature range: -30~70℃
