Application：
BOFAN CABLE provides high watertight and Torque balanced multicore hybrid cables, which are suitable for ships, offshore oil platforms, deep-sea resource exploration, etc. In addition, the cables supply underwater robots with data and energy, both in fixed and mobile systems, also when a robot is pulled through water on the seabed. BOFANCABLE also develops underwater cables for the connection between submersible motor and underwater working appliances, trailing cables for offshore applications, underwater fibre optic cables with steel reinforcement and deep-sea cables. We can custom the Undersea Hybrid Cable according to your requirements.
Cable Components:
Hybrid designs can integrate a wide range of features, fiber optics, coax, air/water hoses, etc.
Optical fibers in stainless steel tubes from 1-24 fibers, single-mode, multi-mode, mix modes and custom specific fibers.
Data signals requiring Ethernet Cat5e and Cat6 signal pairs, RS-232, RS-485, analog, coaxial or shielded components.
Power conductors from 300V to 4.5 kv, carefully selected insulations specific to application.
Water blocked transversally up to 5000 meters, longitudinally up to 1000 meters.
Materials
Conductor: Stranded oxygen-free copper wire for flexiblility and corrosion resistance.
Insulation: PVC/PE/TPEE/FEP
Cores: Color distinction/coding distinction
Filling: Aramid fibers/waterproof yarn/waterproof glue
Shield: Aluminum foil/tin plated copper braid (individual/overall)
Strength layer: Light weight aramid fibers (Kevlar) to meet working and broken strength (100- 50000N)
Jacket: Specially modified waterproof TPU jacket (Color can be made according to customer requirements)
Temperature range: Fixed installation: -40℃ to +90℃, Mobile installation: -30℃ to +90℃ (-40℃ to +150℃ to be specified by the customer)
Characters: Undersea Hybrid Cable with good waterproof performance, acid and alkali resistance, UV resistance, not easy to tear, etc., high reliability in extreme conditions, long cable lifetime which will help to reduce equipment downtime.
