Underwater Cable

Umbilical Cable For Underwater Signal of Underwater Equipment

Umbilical Cable
Conductor: Multi-strand finely stranded oxygen-free copper wire, in line with VDE0295 CLASS6 standard
Insulation: PE
Shielding: Aluminum foil and tinned copper wire braided shielding (density above 85%)
Wrapping: Wrapping with non-woven fabric

GET A QUOTE
CONTACT US

Application:

Umbilical Cable For Underwater Signal of underwater equipment power connection, controlling, signal transmission, etc.

Product Structure:
-4 core 0.5mm2 (20AWG)
Conductor: Multi-strand finely stranded oxygen-free copper wire, in line with VDE0295 CLASS6 standard
Insulation: PE
Shielding: Aluminum foil and tinned copper wire braided shielding (density above 85%)
Wrapping: Wrapping with non-woven fabric
Outer Sheath: PUR
Color: Black

Umbilical Cable structure is composed of 4 core 0.5mm2 cores with double shield. It is highly flexible, resistant to underwater pressure, seawater corrosion, underwater low temperature, oil resistance, ultraviolet resistance, wear resistance, flame retardant, long service life, suitable for the rapid installation of underwater instruments and equipment.https://www.bofan-cable.com/product-category/underwater-cable/
